Melting and holding furnaces

Kipptiegelofen

Gas-fired crucible furnace for rapid melting of aluminium, bronze or copper

• Available for all common crucible types
• Capacity from 125 kg to 1000 kg
• Melting capacity from 100 kg/h to 450 kg/h
• Burner output from 100 kW – 1000 kW.
• For oil burners, natural gas or propane burners

Optionally also in an electrically heated version!

Fixed crucible furnaces

Electrically or burner heated crucible furnace for melting and holding aluminum alloys

• Capacity from 35 kg to 1500 kg
• Melting capacity from 30 kg/h to 350 kg/h

• Electrical power from 18 kW to 120 kW
• Keeping warm with 3 kW/h to 9 kWh.

• The economical solution for holding non-ferrous metals

• Robust furnace design suitable for foundries
• Protected heating coil semi-embedded in
ceramic heating plates
• All-round, very even heat radiation

• Ideal heat transfer and long crucible service life

Accesories

• Impeller stations with crane track
• Crucible pullers
• Launders and transport ladles
• gas-heated ladle heating stations

holding furnace

More up-to-date than ever - beat the electricity prices with our energy saver!

The modern crucible-less furnace.

Low connection values with optimal warming quantities
(11 kW for 500 kg Al)! !

• Optimum use of energy through direct radiant heat
and lightweight insulation.
• Infinitely variable power control of the heating
• Melt overheating protection
• Individual arrangement and design of scoops
and filling hole.
• Fast draining and alloy change through attached
tilting device.
• Tub overfill protection
• Quick and easy cleaning of the tub
• Low-wear lining of the tub

The crucible-less furnace significantly reduces your operating costs within an environmental and user-friendly overall concept!
